NameOTV-DS9H H265 H264 UHD 4K Streaming IPTV Decoder
Brand:Dibview
Product Name:OTV-DS9H H265 UHD HEVC 4K Streaming Decoder
Input:IP
Output:HDMI
Decoding:H.265 & H.264
USB3.0:Yes, support
Application:For Real Time IPTV

Product Description

Overview:


OTV-DS9H H265 HEVC 4K Streaming Decoder is DIBVIEW professional IPTV decoder developed based on the embedded hardware platform. This decoder with 1*HDMI output port, which also support H.265, H.264 and other mainstream encoding format decoding, adding the strong decoding performance, excellent network agility, it become more and more popular, besides that, it also supports 4*1080P or 9*720P resolution output.



OTV-DS9H H.265 HEVC 4K Streaming Decoder, support 1 channel 4K Ultra HD output, it is a new generation decoder. The product adopts embedded operating system, which has the characteristics of stability and reliability, high real-time performance, low power consumption, flexible group network, and strong expandability. Currently it can be widely used in variety of field such as Hotel IPTV system, remote education, news interview etc



Key Features:


  • Support H.265, H.264 and other mainstream code stream decoding;

  • Powerful decoding capabilities, support simultaneous real-time decoding of 4 channels of 1080P, or 9 channels of 720P and below resolution;

  • HDMI output resolution supports up to 4K (3840*2160@30HZ);

  • Support SRT/HLS/RTMP/RTSP/HTTP/UDP/MULTICAST/Onvif and other mainstream network protocols;

  • Support standard TS stream format audio and video stream decoding

  • Support AAC, G.711 audio codec, and video and audio streams support standard TS and ES stream formats.

  • Supports URL decoding from encoding devices using URL method;

  • Supports platforms to integrate devices in SDK.


Technical Specifications:



Item

Description

Video Parameters

Output Resolution

Output Resolution: 4K:3840*2160@30Hz;

2K:2560*1440@60Hz;

1080P:1920*1080@60/50Hz;
SXGA:1280*1024@60/50Hz;
720P:1280*720@60/50Hz;
XGA:1024*768@60/50Hz;

Encoding & Decoding

Decoding Type

HEVC/H.265 Or H.264 /AVC

Decoding Ability

1CH 4K@30Hz, 4CH 1080P30, or 9CH 720P and below resolutions

Audio Decoding

HE-AAC, AAC-LC, G.711A

Picture Processing

Picture Segmentation

1/2/3/4/6/8/9 /Customized

Protocol

Support SRT, Onvif, RTSP, RTMP, HTTP, UDP/Multicast

Peripheral Interface

Video Output

1-Ch HDMI

Audio Output

1*Output, 3.5mm interface (level: 2.0Vp-p, impedance: 1KΩ)

SD Card

Contains 1 M.2 interface, which can be
inserted into a SATA bus interface solid state drive (optional)

Network Port

1*10M/100M/1000M adaptive network interface

USB Port

1 USB2.0 Host

Low-speed Interface

1-Ch RS-232

The Working Environment

Dimension

113x76x23mm

Gross Weight

0.125KG

Temperature

-20°C~+55°C/10%~90%RH

Input Voltage

DC5.5/2.1 interface, DC12V

Power Consumption

≤ 8W



Applications:

Agencies, TV & Pro Radio and Sports

Organizations, Conferences and Worship

Remote Video Conference

IPTV/OTT system

Government, Education and Music

Digital Signage Project

Video Monitoring
