NameOTV-M40 ProHD UHD Streaming 4K H.265 Video IPTV Decoder
Brand Name:Dibview
Model Number:OTV-M40
Product name::Streaming 4K H.265 Video IPTV Decoder
Output signal:HDMI/CVBS/VGA
Resolution:Up to 4K@30fps
Decoding format:HLS/RTSP/HTTP TS/HTTP FLV/RTMP/UDP
Video Compression:H.264/H.265 Baseline/Main/High Profile
OSD:Support

Product Description

Overview:


OTV-M40 ProHD UHD H.265/H.264 4K Streaming Decoder with HDMI/CVBS/VGA output, which used advanced H.265 Video compression technology, integrated data transmission over HLS/RTSP/HTTP TS/HTTP FLV/RTMP/UDP With embedded operating system,



OTV-M40 ProHD UHD H.265/H.264 4K Streaming Decoder provides the features of stability, excellent network agility, which makes it a new generation network media decoder. Besides that, with embedded linux system designing makes this device widely used in variety of professional field where required 24/7/365 running, such as point to point contribution system, education, health care, IPTV, conference, remote education, news interview, court, public security, banking, transportation and other industry application.


Key Features:


  • Output Signal: HDMI/CVBS/VGA

  • Video Compression: H.265/HEVC main profile, H.264/AVC baseline/main/high profile

  • Up to 4K@30fps

  • With HLS/RTSP/HTTP TS/HTTP FLV/RTMP/UDP protocol

  • Support Multi-channel decoding at the same time

  • low Latency: less than 200ms working with DIBVIEW encoder over LAN

  • Support B frame

  • Humanization GUI, easy to check the OSD,IP address and other decoding parameters on field

  • Web-based management


Technical Specifications:


Item

Description

Network Protocol

Protocol

Support HLS/RTSP/HTTP TS/HTTP FLV/RTMP/UDP

Video Decoding Capacity

Decoding format

H.264/H.265 Baseline/Main/High Profile Level4.2

Frame Rate

1-60fps

Bit rate(kbit)

32kbps-32Mbps

Resolution

Up to 4K@30

Channel number

Up to 4 Channels

Audio Decoding Capacity

Decoding format

G711A/G711U/AAC+/AAC++/MP2/MP3

Audio mode

Mono/Left, Right/Stereo

Sample rate(Hz)

8KHz/11.25KHz /22.5KHz /44.1KHz /48KHz

Channel number

1 Channel

Video Output

HDMI

4K@30fps,1080P@60/50fps,1080P@30/25fps,720P@60/50fps,576P@50fps,480P@60fps

VGA

The same as HDMI

CVBS

720x576@25fps

Color

Brightness, Contrast, Hue, Saturation can be adjustable

Audio Output

HDMI audio embedded

48KHz stereo output

3.5mm

Stereo output (Left & Right)

Audio control

Enable/Disable

The Working Environment

Warranty

3 years with free telephone support

Network

1000M

Management

Web management

Power

12V/DC, 2A

Power Consumption

<5W

Working temperature

-20°C +60°C

Working humidity

<90%, non-condensing

Dimension

115mmx150mmx28mm

Weight

0.5kg



Applications:


Agencies, TV & Pro Radio and Sports

Organizations, Conferences and Worship

Remote Video Conference

IPTV/OTT system

Government, Education and Music

Digital Signage Project

Video Monitoring
