Your Location : Home >> Product Center >> SDI Decoder >> OTV-DC220 IP Streaming to HDMI SDI VGA Decoder

Name	OTV-DC220 IP Streaming to HDMI SDI VGA Decoder
Brand Name:	Dibview
Model Number:	OTV-DC220
Product name:	OTV-DC220 IP Streaming to HDMI SDI VGA Decoder
Video Output:	1SD/HD/3G SDI,1DVI-I (compatible with HDMI/DVI and VGA)
Output Signal types:	SD-SDI(270M), HD-SDI(1.485G) and 3G-SDI(2.97G)
Output formats:	1080p60/50, 1080p/25/30, 1080i60/50, 720p60/50
HDMI:	1.3
DVI:	1.0
Video Decoding:	H.264
Audio Decoding:	AAC-LC/G.711 (aLaw/uLaw)
Product Keywords:	ip to 1080p sdi video decoder
Decoding delay:	≤200ms
Media transmission protocols:	RTP/RTSP RTP unicast/multicast, RTMP

Product Description

Overview:

OTV-DC220 IP Streaming TO SDI HDMI VGA Live Video Decoder is a professional hardware decoding device. It is capable of independently decoding incoming streams from IP Camera, stream media server, or any encoder (based on HLS, SRT, RTSP, RTMP, RTP & more, unicast and multicast). The output interface can be SDI and DVI-I (HDMI/VGA). This device decodes IP video from encoders via Ethernet.

OTV-DC220 IP Streaming TO SDI HDMI VGA Live Video Decoder is an excellent Hardware decoder for professional broadcast level IPTV & OTT system, Point to Point Application, hospitality Hotel IPTV system application, remote multi-window video conference, remote education and remote medical treatment, live broadcasting.

Key Features:

H.264 Video Decoding
High compatibility
Dual output SDI & DVI ( HDMI/VGA compatible )
7*24h working mode
SDK provided
SRT Supported

Technical Specifications:

Item	Description
Input
1*RJ-45
USB: 1*USB 2.0 Type-A
Output
Video output	1SDI, SD-SDI(270M,HD-SDI(1.485G),3G-SDI(2.97G); 1DVI-I, HDMI1.4 /DVI 1.0/VGA
Output format	SDI/HDMI: Up to 1080P60Hz; VGA: Up to UXGA
Media protocol: SRT/RTMP/HLS/TS over UDP/RTP/RTSP,etc.
Audio output: SDI/HDMI embedded or analog line-out output
SDI transmission distance: Belden 1694A cable standard: SD SDI≥350m; HD SDI≥180m; 3D SDI≥100m
Decoding
Video Decoding: H.264
Audio Decoding: AAC/G.711
Decoding delay: <200ms
Decoding ability: Only support single screen output
Management
Configuration Interface: web-based UI
Connector: RJ45
The Working Environment
Dimension	14010528mm
Gross Weight	0.38KG
Operating Temperature	0 to 45(For working), -20 to 60(For storing)
Input Voltage	12V/DC 1A

Product Advantage:

Strong decoding ability, strong error-resistance, low latency.

With Dibview unique image enhancement and fault-tolerant technology, it has powerful error resistance for video encoded at low bitrate with up to 10% packet loss, excellent image output can be obtained.

Decoding latency can be less than 200 ms under a typical network environment with Dibview intelligent latency control technology.

Decoding of H.264 encoded video and AAC/G.711 encoded audio at bitrate of 40Mbps supported.

High compatibility, SDI + DVI dual output, wide application.

It supports RTMP/HLS/TS over UDP, RTSP protocols as well as SIP/VOCP, it can also be connected with different kinds of encoding device, streaming media servers and IP cameras.

SRT supported to ensure secure and reliable transmission.

With dual output SDI & DVI (HDMI/VGA compatible), and the resolution can be self-defined.

Outputs of SDI/ HDMI can be up to 1080p60, and VGA up to UXGA solution.

Analog audio and embedded SDI/ HDMI audio can be output simultaneously.

Audio mixing, tally and column loudspeaker indicating design supported.

Portable size, low power consumption, multifunctional, 24h continuous operation available.

Dimension is 138mm*105mm*27mm.

Power consumption less than 5w.

With image scaling function, the output video can be scaled as well as frame rate conversion, in order to adapt different output video formats

Applications:

Multimedia Project

Organizations, Conferences and Worship
